NETGEAR MSM4310-100NES (M4350-8M2V) Managed Switch
- 8 x 2.5G RJ45 Ethernet PoE++ Ports
- 2 x 25G SFP28 Port
- Certified for AV over IP
- 140 Gb/s Switching Capacity
- 104.16 Mpps Forwarding Rate
- 1.8 GHz Cortex A57 Quad-Core CPU
- 4GB RAM
- Desk & Rack Mountable Design
- 119W Base Power Budget
Designed for AV over IP applications, the AV Line M4350-8M2V 8-Port 2.5G PoE++ Compliant Managed Switch from Netgear allows you to quickly get up and running. It features eight 2.5 Gb/s PoE++ compliant RJ45 ports that each deliver up to 60W of power with a 119W base budget to operate your compatible equipment.
Additionally, its two SFP28 slots support up to 25 Gb/s fiber uplinks. Equipped with 1.8 GHz Cortex A57 Quad-Core processor and 4GB of DDR4 memory, this Layer 3 switch supports a 140 Gb/s switching capacity and 104.16 Mpps forwarding rate.
Its half-width design allows you to install two M4350-8M2V switches onto your rack while occupying 1 RU of space. Manage the switch through the Netgear AV user interface and ENGAGE Controller, which includes preconfigured profiles for most major audio, video, and lighting protocols.
Designed for AV Over IP
With NETGEAR IGMP Plus built in, there’s little to no setup required for clear audio and video delivery. Multicasting is enabled right out of the box.
PoE Expansion
The included APS254W power adapter enables an up to 119W PoE budget. You can add up to two more to increase the budget to 551W while providing failover redundancy.
Quiet Design
Intelligent fans with a configurable quiet mode allow you to broadcast without disruptions.
Automatic Configuration
Auto-LAG and Auto-Trunk functionality automatically configure uplinks between multiple M4350 and M4250 switches.
Stacking Mode
Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover.
Compatibility
AVB, Dante, Q-SYS, AES67, NVX, AMX, IPMX, NDI 4/5/6, ZeeVee, Aurora Multimedia, Kramer, Atlona, LibAV, Visionary, SDVoE, and more.
SMPTE ST 2110
SMPTE ST 2110 Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications.
| Weight | 7.58 kg |
|---|---|
| Dimensions | 42.67 × 38.1 × 14.22 cm |
| Other | Priority Port Speed: 2.5 Gigabit IGMP Support: Advanced (NETGEAR IGMP Plus?) Jumbo Frame Support: Yes, up to 12 KB AVB Support: Yes, included Acoustics: Silent Mode 32.1dB@25?C |
| Power | Power Consumption: Maximum PoE with: 682W/hour Without PoE: 82W/hour Idle without any port connection: 61.2W/hour Uyumlu PSU Modelleri: APS254W External power adapter (maks. 3 Pieces) |
