NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W)
- 8 x Gigabit Ethernet PoE+ Ports
- 2 x 10G SFP+ Slot
- 56 Gb/s Switching Capacity
- 41.67 Mpps Forwarding Rate
- 1.25 GHz ARM A9 CPU
- 2GB RAM
- Desktop & Wall Mountable Design
- 220W Power Budget
- AVB Support
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Designed primarily for access and edge AV over IP applications, the AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch from Netgear is pre-configured with out-of-the-box functionality to quickly get you up and running.
It features eight PoE+ compliant RJ45 ports that each deliver up to 30W of power with a 220W budget to operate your compatible equipment. Additionally, its two Gigabit SFP slots help ensure strong integration with your devices while its flexible mounting design allows you to place it on a desk or wall.
Featuring a 56 Gb/s switching capacity, a 41.67 Mpps forwarding rate, and a simplified user interface with Netgear IGMP Plus providing multicast functionality, the AV Line M4250 is designed to minimize hassles so you can focus on making quality broadcasts.
Easy Configuration
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.
Pre-Configured for Multicast
Netgear IGMP Plus provides multicast functionality right out of the box for most AV over IP applications. There’s little to no setup required for clear Video over IP delivery.
Quiet Design
The fanless design provides silent operation, so you can broadcast without disruptions.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4250 and M4300 switches.
AVB Support
Updating to the latest firmware enables the Audio Video Bridging (AVB) profile, allowing this switch to connect to compatible devices with improved synchronization, reliability, and performance.
| Weight | 2.72 kg |
|---|---|
| Dimensions | 28.96 × 22.86 × 9.4 cm |
| Networking I/O: | 8x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at) 1x RJ45 Gigabit Ethernet WAN 1x SFP Gigabit Ethernet WAN 1x RJ45 Gigabit Ethernet LAN |
| Other I/O: | 1x USB-C 1x USB-A |
| Stackable: | No |
| Layer Services Supported: | Layer 2, Layer 3, Layer 4 |
| Supported Protocols: | TLS Link Aggregation Port Mirroring DHCP Server IGMP Snooping DoS IPv6 DMZ Auto-VoIP RADIUS IPv4 |
| Jumbo Frames Support: | 12, 000 Bytes |
| MAC Address Table Size: | 16K |
| Security Features: | DHCP Snooping DoS Attack Prevention RADIUS Authentication Storm Control |
| Forwarding Rate: | 41.67 Mpps |
| Switching Bandwidth: | 56 Gb/s |
| Packet Buffer: | 16 Mb |
| CPUP: | Single-Core: Up to 1.25 GHz Cortex A9 |
| Flash Memory: | 256 MB |
| Memory: | 2 GB |
| PoE Power Budget: | 220 W |
| Power Draw: | 257.9 W (Max) 9.51 W (Standby) |
| Power Supply Type: | External |
| Certifications: | BSMI, CB, CCC, CE, CSA, EAC, EN, FCC, ICES, RCM, VCCI |
| Cooling System: | Fan (Noise Level 19.3 dB) |
| Mean Time Between Failures (MTBF): | 1.4 Million Hours |
| Indicator Lights: | Yes |
| Rack Mountable: | No |
