NETGEAR GS724TPPv3 – 24P GE POE+ Smart Switch
- 24 x Gigabit Ethernet PoE+ Ports
- 2 x Gigabit SFP Slots
- 52 Gb/s Switching Capacity
- 38.6 Mpps Forwarding Rate
- Rack Mountable Design
- 380W Power Budget
- Supports Up to 256 VLANs
- Layer 2+ & Layer 3 Lite Features
- 2 x Integrated Fans
- Cloud Management
Grow your small business with powered devices such as IP cameras, access points, and VoIP phones with the GS724TPPv3 24-Port Gigabit PoE+ Managed Switch from Netgear. Designed for easy installation and flexible management, this switch features 24 Gigabit Ethernet ports, each of which supports up to 30W of power with a 380W budget.
With a 52 Gb/s non-blocking switching capacity and 38.6 Mpps forwarding rate, the GS724TPPv3 delivers smooth and fast performance. It also supports up to 256 VLANs. Extensive Layer 2+ and Layer 3 Lite features add security, efficiency, and easy management.
Two cooling fans help to ensure optimal performance without disturbing your environment when mounted onto a rack or desktop. A 1-year subscription to the Netgear Insight management platform is included, which allows you to configure and monitor your network using your mobile device from almost anywhere, anytime.
Netgear Insight Management
Gain simple yet powerful control of your network anytime and anywhere, even across multiple locations using a web-based interface or mobile app. NETGEAR Insight handles your network so you can focus on running your business.
Layer 2 / Layer 2+ Support
Powerful Layer 2+ / Layer 3 Lite features enhance performance, usability, and network efficiency.
Powerful Connectivity and Security
- Advanced VLAN support for better network segmentation
- L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
- Advanced per port PoE controls for remote power management of PoE connected devices, including operation scheduling
- Advanced QoS (Quality of Service) for traffic prioritization including port-based, 802.1p and L2/L3/L4 DSCP-based
- Auto “denial-of-service” (DoS) prevention
- IGMP Snooping and Querier for multicast optimization
- Egress Rate limiting and priority queuing for better bandwidth allocation
- Port mirroring for network monitoring
- Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
- IPv6 management: IPv6 QoS, IPv6 ACL, IPv6 Multicast, and static and dynamic IPv6 address assignment
- Cable test to troubleshoot connection issues
- Easy-to-use Web browser-based management GUI available in English, German, and Japanese
- SNMP v1, v2c, v3 and RMON remote monitoring
| Weight | 4.77 kg |
|---|---|
| Dimensions | 53.09 × 34.54 × 10.41 cm |
| Connection Points | 10/100Mbps Connection Point: Not available Gigabit Connection Point: 24 SFP Connection Point: 2 PoE Number of Ports: 24 |
| PoE | PoE+ (802.3 at): 24 Total PoE Power Budget (W att): 380W |
| Other | Maximum MAC Input port: 16K Buffer Size: 1.5MB MLD Snooping: Not available St atik rota: Not available Host ARP Table: Not available EEE: Yes DoS Prevention: Yes |
| VLAN | VLAN (Number of Designated): 256 VLAN Routing: Not available Dynamic VLAN Assignment: Yes |
| Power: | includedi/External: includedi 100-240VAC 50-60Hz Maximum Power Consumption (W att): 396,95W FAN: 2 Acoustic Noise Level @25?C (dBA):33,60 Operating Temperature: 0?to 50? C |
