Blackmagic 2110 IP Converter 8x12G SFP
10,595.00 Excl. VAT
- Convert 8 x 12G-SDI Devices to SFP Fiber
- 8 x SMPTE-2110 IP SFP Fiber Ports
- UHD 4K Resolution Support
- Redundant Power
- 1 RU Rackmount Design
Available on backorder
Estimated delivery: October 27, 2026 – November 6, 2026
Description
Blackmagic Design 2110 IP Converter 8x12G Overview
Bring your 12G-SDI broadcast gear up to SMPTE-2110 compliance with this 2110 IP Converter 8x12G SFP from Blackmagic Design. The converter provides eight bidirectional 12G-SDI video conversion connections, and it features eight SMPTE-2110 SFP IP fiber ports to extend connectivity over long distances. Its 1 RU design fits in a standard studio rack, as well as a 12G-SDI return input.
Additional information
| Weight | 4 kg |
|---|---|
| Dimensions | 54.86 × 28.7 × 8.89 cm |
| Video I/O: | Input 8x BNC (12G-SDI) Female 1x BNC (12G-SDI) Female (Program) Output 8x BNC (12G-SDI) Female 1x BNC (12G-SDI) Female (Loop Output) |
| Audio I/O: | Output 1x 1/4″ TRS Stereo Analog Female |
| Video Resolution: | BNC Input/Output (4:2:2 YUV) 4096 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080PsF at 25/29.97/30 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps |
| Expansion Slots: | 8x SFP Slot (Occupied by 10 Gb/s SMPTE 2110 IP SFP) |
| Embedded Audio: | LAN (RJ45)/SDI |
| Video Standard Compliance: | SMPTE: ST-2110 |
| HDCP Support: | No |
| HDR Support: | Yes |
| Wireless: | No |
| OS Compatibility: | macOS 13 or Later Windows 10 to 11 |
| Display: | 2.2″ LCD |
| Power I/O: | 2x IEC C14 (100 to 240 VAC ) Input |
| Operating Conditions: | 41 to 104?F / 5 to 40?C up to 90% Humidity |
| Storage Conditions: | -4 to 113?F / -20 to 45?C up to 90% Humidity |
| Rack Form Factor: | 1 RU |
