NETGEAR WAX610W AX1800 Dual-Band Wi-Fi 6 Access Point
- Wi-Fi 6 (802.11ax)
- Up to 1.8 Gb/s Throughput
- 2.4 GHz / 5 GHz (Dual-Band)
- 1 x Gigabit Ethernet PoE In WAN Port
- 4 x Gigabit Ethernet LAN Ports
- 1 x PoE Out Port
- Mesh Compatible
- Up to 1000 Square Foot Coverage
- Wall Mountable
- Works with Insight App
Ideal for hotels, multi-dwelling units, and classrooms, the WAX610W AX1800 Dual-Band Managed Wi-Fi 6 Access Point makes it easy to grow your wireless network coverage. Designed for flush wall mounting, this Wi-Fi 6 (802.11ax) access point can transfer up to 1.8 Gb/s over the 2.4 and 5 GHz bands with compatible devices while eliminating dead spots with a 1000 square foot range.
With four Gigabit speed LAN ports, you can connect wired devices. Connecting the Gigabit WAN port to a PoE compatible switch allows you to transfer data and power over a single cable. You can also add a separately purchased power adapter, which would enable the PoE out compatible LAN port.
Performance
- Seamless Mesh Wi-Fi
- Seamlessly expand your Insight managed mesh network.
Easy Deployment
One PoE Gigabit port for easy setup, plus four LAN ports to connect to IP phones, smart TVs, and more.
Security
- Multiple SSIDs
- With support for up to eight SSIDs, you can separate and secure networks for admin, guests, employees, and IoT devices.
Business-Level Security
You wireless signal is protected with WPA3 encryption.
Separate VLANs
Keep employee and guest traffic safely separated.
| Weight | 0.38 kg |
|---|---|
| Dimensions | 12.95 × 10.92 × 3.3 cm |
| Wi-Fi: | Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (2 x 2 |
| Antenna Gain: | 3.4 to 3.8 dBi |
| Supported Protocols: | SSID |
| Antenna Placement: | Internal |
| Bluetooth: | No |
| Throughput: | 1800 Mb/s Total 2.4 GHz: 600 Mb/s 5 GHz: 1200 Mb/s |
| Networking I/O: | 1x RJ45 Gigabit Ethernet WAN PoE (Unspecified) 1x RJ45 Gigabit Ethernet LAN PoE (Unspecified) 3x RJ45 Gigabit Ethernet LAN |
| USB Sharing Support: | Yes |
| Wireless Security: | WPA, WPA-Enterprise, WPA2, WPA3 |
| Lock Slot: | No |
| Operation Modes: | Access Point, Bridge, Mesh, Repeater |
| Max SSIDs Supported: | 8 |
| Mobile App Compatible: | Yes: Android & iOS |
| Media Card Reader: | Yes |
| Supported IEEE Standards: | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11i, 802.11n, 802.3af (PoE 15.4 W), 802.3at (PoE+ 30 W) |
| Power Consumption: | ?20.19 W |
| Environmental Resistance: | No |
| Operating Conditions: | 32 to 104?F / 0 to 40?C |
| Mount Options: | Wall |
