Warm Audio WA76-D Discrete FET Compressor/Limiter
2,999.00 Excl. VAT
- Single-channel clean-gain discrete FET compressor/limiter
- Re-creation of the iconic D-Rev ’76 with added recording features
- 100% analog discrete audio circuit path
- 600Ω input impedance attenuator
- Selectable 10kΩ input impedance to match modern audio interface specs
- Class A line-level output amplifier
- Custom original-spec, large-core CineMag USA input and output transformers
In stock
Additional information
| Weight | 4.613 kg |
|---|---|
| Dimensions | 64.01 × 29.97 × 13.97 cm |
| Audio Circuit Type: | Analog (Solid-State) |
| Buffer: | Selectable Active or True Bypass |
| Input Impedance: | 600 Ohms or 10 Kilohms (Selectable) |
| Frequency Response: | 20 Hz to 20 kHz (?1 dB) |
| Gain: | Up to 53 dB |
| SNR: | 86 dB |
| THD: | -64 dB (at -8 dBu) |
| Audio I/O: | 1x XLR 3-Pin Line Input 1x 1/4″ Line Input 1x 1/4″ TRS Input (Insert) 1x 1/4″ TRS Input (Link) 1x XLR 3-Pin Line Output 1x 1/4″ Line Output 1x 1/4″ TRS Output (Insert) 1x 1/4″ TRS Output (Link) |
| Power Source: | AC Input |
| Mounting: | Front: 4x Standard Rackmount Screw |
About brand
Analogue-inspired microphones, preamps and processors for modern studios.
