Blackmagic Design DeckLink 4K Extreme 12G – Capture and Playback Card
3,956.00 Excl. VAT
- 8-Lane PCIe Gen2 I/O Card
- Multi-Rate 12G-SDI & HDMI Connections
- Supports UHD 4K & DCI 4K up to 60 fps
- Single & Dual-Link 4:4:4:4/4:2:2 Signals
- 3D Stereoscopic SDI Output at 4:4:4:4
- Up/Down/Cross Conversion
- Optional Optical Fiber I/O Modules
- Breakout Cable for Analog / RS-422
- Genlock & Deck Control
- Compatible with Mac, Windows & Linux
Available on backorder
Extreme 4K Digital Cinema Capture for Serious Creators
Advanced digital cinema capture card featuring full frame DCI 4K input and output via 12G‑SDI! You get dual link multi rate 12G‑SDI connections that work with SD, HD and Ultra HD even in Ultra HD 60p, as well as full frame DCI 4K at 4096 x 2160 resolution up to 25p! Capture 10‑bit YUV or full color bandwidth 12-bit RGB. Includes AES/EBU audio, up, down and cross conversion, plus built in 3D stereoscopic output at full bandwidth 4:4:4:4 RGB! No other capture and playback card supports more video formats and video connections!
Jam-packed with powerful connectivity
Equipped with two 12G-SDI connections, along with in/out HDMI 2.1 connections, DeckLink 4K Extreme 12G flaunts enough connectivity to accommodate multichannel and high-resolution video workflows. You get support for the gamut of SD, HD, Ultra HD, and 4K DCI formats, and you can use the free DeckLink SDK to configure up to four video streams in any direction, format, or frame rate up to 4K DCI 60p for true multichannel capture and playback. You also get support for 8- and 10-bit YUV 4:2:2, along with 10- and 12-bit RGB 4:4:4 with full Rec. 2020 color. Moreover, DeckLink 4K Extreme 12G enables you to work at up to 120 frames per second in HD and 4K. Finally, DeckLink 4K Extreme 12G’s onboard balanced analog and AES/EBU audio channels make working in your sound a cinch.
Broad-gauge software compatibility
Decklink 4K Extreme 12G works seamlessly with more editing, design, and video software applications than nearly any other capture card available. Furthermore, it’s also compatible with macOS, Windows, and Linux, so it supports a massive breadth of computer hardware. Editors can get up and running with DaVinci Resolve, Final Cut Pro, Media Composer, or Premiere Pro; VFX artists can create stunning visual effects with Fusion, After Effects, or Photoshop. You can use DeckLink 4K Extreme 12G to perform unparalleled color correction using DaVinci Resolve or dive into audio production with Pro Tools. No matter the job, it’s a sure bet that DeckLink 4K Extreme 12G will be able to tackle it with impressive results.
| Weight | 0.86 kg |
|---|---|
| Dimensions | 22.48 × 15.49 × 8 cm |
| Connections |
SDI Video Inputs SDI Video Outputs Analog Video Inputs Analog Video Outputs Analog Audio Inputs Analog Audio Outputs Optical Fiber Inputs/Outputs (Optional) AES/EBU Audio Inputs AES/EBU Audio Outputs SDI Audio Inputs SDI Audio Outputs HDMI Video Inputs HDMI Video Outputs HDMI Audio Inputs HDMI Audio Outputs Sync Input Device Control Computer Interface |
| Supported Codecs |
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10‑bit 4:4:4. |
| Standards |
SD Video Standards HD Video Standards 2K Video Standards (SDI Only) Ultra HD Video Standards 4K Video Standards 3D SDI Video Standards *SDI only 3D HDMI Video Standards SDI Compliance SDI Metadata Support Audio Sampling SDI Video Sampling SDI Color Precision Color Space HDR Support HDMI Video Sampling HDMI Color Precision HDMI Configuration Multiple Rate Support Copy Protection |
| Processing |
Ultra HD Down Conversion HD to SD Down Conversion HD Up Conversion HD Cross Conversion Real Time Effects Colorspace Conversion 3D Processing |
