Blackmagic 2110 IP Converter 3x3G
- Converts 3G-SDI to 2110 IP Video Systems
- 3G-SDI Inputs, Outputs & Loop Outputs
- Integrated 2.2″ LCD Display
- Resolutions up to 1080p60
- PoE+ Support
Additional information
| Weight | 1.24 kg |
|---|---|
| Dimensions | 28.7 × 18.29 × 6.6 cm |
| Inputs/Outputs: | 1x RJ45 |
| Video Inputs: | 3x BNC (3G-SDI) |
| Audio Inputs: | No |
| Video Outputs: | 3x BNC (3G-SDI) 3x BNC (3G-SDI) (Loop Output) |
| Other I/O: | 1x BNC Reference Output 1x USB-C Control, Firmware |
| Expansion Slots: | No |
| Input Video Format: | RJ45 / SDI (8/10-Bit 4:4:4 RGB) 1080p at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps RJ45 / SDI (8/10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
| Output Video Format: | RJ45 / SDI (8/10-Bit 4:4:4 RGB) 1080p at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps RJ45 / SDI (8/10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
| Embedded Audio: | LAN (RJ45)/SDI: 16-Channel |
| Video Standard Compliance: | SMPTE ST-2110 |
| HDR Support: | Not Specified by Manufacturer |
| Display Size: | 2.2″ |
| OS Compatibility: | macOS 12 to 13 or Later Windows 10 (64-Bit Only) Windows 11 |
| Power I/O: | 1x IEC C14 Input |
| Operating Temperature: | 32 to 104°F / 0 to 40°C |
| Storage Temperature: | -4 to 140°F / -20 to 60°C |
| Operating Humidity: | 0 to 90% () |
