Kiloview RMG-300 V2 Media Gateway Module
AED 2,970.000 Excl. VAT
- For RU01, RU03 & RU03S Rackmount Chassis
- Resolutions up to UHD 4K60 via HDMI
- Resolutions up to 1080p60 via 3G-SDI
Available on backorder
RMG-300 V2
MediaGatewayCard
Kiloview Media Gateway Card support dual-channel 4K resolution.
Do you find it hard to pick the right one in our I/O Card Family to fit your workflow?
Here is the chart for your better understanding:
| Weight | .38 kg |
|---|---|
| Dimensions | 14 × 10.5 × 2.8 cm |
| Network: |
2*100M/1000M RJ45 adaptive Ethernets |
| Decoding output: |
1*SD/HD/3G-SDI, up to 1080P 60Hz |
| Applicable frame: |
RU01, RU03, RU03S |
| Analog audio output: |
1*3.5mm Line out |
| Analog audio input: |
1*3.5mm Line in |
| USB: |
1*USB 3.0 Type-C |
| Access protocol: |
NDI-HX/SRT/RTSP/RTMP/TS-UDP/HTTP, (NDI ,HX means NDI ,HX Version 2.0, SIP/ONVIF (customize) |
| Output protocol: |
NDI ,HX 2.0/SRT/RTSP/RTMP/TS-UDP |
| Protocol conversion: |
9 channels1080P video conversion |
| Streaming distribution: |
50 channels of RTSP, 36 channels of RTMP/SRT |
| Streaming distribution capability |
9 channels*4 channel 1080P |
| Number of decoding: |
4K 30Hz H.264/H.265: up to 4 simultaneous channels |
| Video decoding standard: |
H.264, H.265 |
| SDI output format: |
1080P60/59.94/50,1080P30/29.97/25/24/23.98,1080i60/59.94/50.720P60/ 59.94/50, 576i50, 480i60 |
| HDMI output format: |
4K 3840×2160@60/30, 1080p60/50, 1080p24/25/30, 1080i60/50, 720p60/50 |
| Video rate range: |
128Kbps ~ 40Mbps |
| Audio decoding: |
AAC G.711 (aLaw/uLaw) |
| Audio rate range: |
AAC: 8Kbps ~ 320Kbps G.711: 64Kbps |
| Decoding delay: |
≤200ms |
| Split display style: |
Support 1/2/3/4/5/6/7/8/9 splitting; |
| Management interface: |
Web |
| Remote management: |
Support |
| Remote firmware upgrade: |
Support |
| Operating temperature: |
-25 ~ 60°C |
| Dimension & weight: |
140*105*28mm (5.5”*4.1”*1.1”/380g/13.4oz) |
| Power consumption: |
≤6W |
| Power supply: |
≤6W |
| Remark: |
NDI ,HX means NDI ,HX Version 2.0 |
